Description
>Modular design, easy to install and transport;
>The cold aggregate feeder is equipped with frequency conversion speed control,
>Synchronous proportional automatic control and adjustment, safe and reliable;
>The hopper is equipped with a screen, the two fine hoppers will automatically vibrate when
>the material is blocked, the lack of material will alarm, and the discharge door can be adjusted;
>The belt conveyor is equipped with correction and cleaning devices;
>The repeatedly optimized design of the lifting blade and the stainless steel insulation layer can
>Effectively reduce the heat loss of the drying drum, save fuel consumption and greatly improve
>the thermal efficiency;
>The burning zone of the drying drum adopts wear-resistant and heat-resistant materials with
long service life;
>Gas secondary ignition, high reliability of ignition;
>Unique purge pipeline, effectively prevent oil circuit blockage.
| Capacity | 60 ~120Tons Per Hour |
| Drying drum | Φ1500*6500mm |
| Drying & Mixing Drum | 6.5kg/ton |
| Fuel Consumption | Diesel consumption: 6.5kg /ton |
| Hot Asphalt Temperature | 130ºC-165ºC(adjustable) |
| Air Emissions | ≤100mg/Nm³ |
| Working Noise | ≤70db(A) |
| Operation | Manual, automatic, and semi-automatic Operation |
| Installation Power | 135kw |
| Electrical Design | 220V/380V-50Hz |
